Hydrostatic Pressure Tester
Standards
ISO 1167
ASTM D 1598
ASTM D 1599
Application
For testing the resistance of plastic pipes and fittings in PE, PEX, PVC, PP and PB, the GT-HPS series is designed primarily for measuring internal pressure and short-time hydraulic bursts at a constant internal water pressure at a constant temperature, as well as for pressure testing internal pressure and short-time hydraulic burst tests.
Highlights
pressure testing of even large PE pipe samples
Burst test, internal-pressure test
Easy to install and to operat
High accuracy pressure control
Online support via internet connection
Features
Thanks to the high pressure water hydraulic pump and big capacity pressure reservoir to ensure maximum capacity at all times.
Modular pressure testing system without any need for maintenance.
A self-developed solenoid valve greatly extends its life, no further maintenance is needed.
It enables the testing of large PE plastic pipes and fittings under pressure. Moreover, the compact and modular design allows 20 independent pressure stations to be connected over a small and convenient area of just 0.5 m2.
Moreover, the system is very economical to run due to its low energy consumption.
Software Features
It is intelligent to distinguish the size and material of specimen, then provide perfect pressure rising solution and algorithm.
For the pipes with big rate of expansion has the properties of rapid pressure rising rate and steady at constant pressure.
Specimen pre-treatment, real-time monitoring,, storage of test data, protection from power interruption at power off (memory), and recovery while powered on are built in.
There are electronic, mechanical, and software protection measures.
Technical specifications
Capacity: 1 to 20 stations
Output: up to 100, 160, 200 bar
Pressure resolution: 0.01 bar
Timing range: 0～10000h
Time resolution: 1s
Timing mode: Counter-up, counter-down
Associated equipment
Test tank
End closures
Laboratory saw
OUR SERVICE
We have 20-year expericen design team
We have professional QC team to ensure product quality
We have skilled staff to provide you perfect finished products
We provide you ontime aftersale service
FAQ
Q: How to get an operative offer?
A: Please sent us your technical requirement in detail, e.g. the test standards, the material of test piece, the max. test pressure. Then you will get the quotation within 24hours.
