Standards
· ISO3127
· BS EN744
· BS EN1411
· ISO11173
Application
It is used to determine the resistance to external blows of thermoplastics pipes of circular cross-section. Test pieces are subject to blow from a falling striker, of specified mass and shape, dropped from a known height onto specified position around the circumference of the test piece. The true impact rate of the batch, or production run from an extruder, is estimated.
The maximum value acceptable for the TIR is taken to be 10%.
There are two test methods--round-the-clock method and staircase method.
Features
· The function of anti-rebound device has the catching rate of 100%.
· The import AC servo system will guarantee the high locating precision and fast rising speed.
· The impact height may be set between 50 to 2000mm, also the impact height may be calibrated automatically.
· Automatic personal safeguards are considered, e.g. specimen door, anti-shock and striker window safeguard. Test can only be carried out when the test chamber and window are closed.
Technical specifications
ISO 3127 / EN 744 |
Drop height (mm) | 2000 |
Tup mass (kg) | Up to 16 |
Pipe diameter (mm) | 10 to 630 |
ASTM D 2444 |
Drop height (mm) | 3000 |
Tup mass (lb) | 6, 12, 20 and 30, Tup A, B and C |
Pipe diameters (mm) | 10 to 630 |
UL 651 |
Drop height (mm) | 3350 |
Tup mass (lb) | 20 and 75 |
Pipe diameter (inch) | Up to 6 |
Test methods | round-the-clock and staircase |
